Center Pivot Disc Mower Conditioner FC 303 GC/RGC
Features
Central draw-bar enabling mowing back and forth on the same side of the field - New GYRODINE® swivel hitch - Compact and low profile cutter-bar - Conditioning with free swinging fingers or roller conditioner - Constant float suspension over a very large travel range - Centralized suspension adjustment - Centralized adjustment of the cutting height with indicator - Belt drive - All sub-assemblies mounted on vibration isolation joints - Reduced maintenance.
Specifications
| Working width (m) | 3 |
| Working width (inches) | 9'10" |
| Transport width (m) | 3 |
| Transport width (feet) | 9'10" |
| Number of discs with protecting skids | 6 |
| PTO speed (rpm) | 1000 |
| Swath width (m) | 1 - 2.2 |
| Conditioning | With free swinging flail fingers or rubber rollers |
| Conditioning rotor speed (rpm) | 660/1000 |
| Swath width (feet) | 3'4" - 6'6" |
| Weight approx. (kg) | 2350 (GC) - 2450 (RGC) |
| Weight (lb) | 5170 (GC) - 5390 (RGC) |
| Minimum power requirement for PTO (kW) | 59 |
| Minimum power requirement for PTO (hp) | 80 |
| Tractor hydraulic equipment | 1 double acting valve + 1 single acting valve |
